High Speed CNC Wood Carving Machine (9001200 mm) with 3 kW Spindle for 3D Carving

Send Inquiry

Request To Call Back

High Speed CNC Wood Carving Machine (9001200 mm) with 3 kW Spindle for 3D Carving

Name: High Speed CNC Wood Carving Machine (9001200 mm) with 3 kW Spindle for 3D Carving
Brand: Infinity Designs Solutions
Price: 650000 INR
Availability: InStock

Price 650000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

High Speed CNC Wood Carving Machine (9001200 mm) with 3 kW Spindle for 3D Carving Specification

Product Type
High Speed CNC Wood Carving Machine

General Use
3D Wood Carving, Panel Processing, Furniture Decoration

Material
Wood, MDF, Plastic, Acrylic

Type
CNC Router

Capacity
8-10 Sheets/Day (Depending on Job)

Weight (kg)
Approx. 950 kg

Computerized
Yes

Automatic
Yes

PLC Control
Yes

Bar Feeder
No

Power Source
Electric

Power Consumption
3.5 kW

Rigidity
High Rigidity Industrial Frame

Voltage
220V/380V, 50/60Hz

Motor
Step Motor Drive System

Table Size
900 1200 mm

Spindle Speed
0-24000 RPM (Variable)

Axial Choice
XYZ 3 Axis

Dimension (L*W*H)
1650 1400 1750 mm

Feature
High Speed, 3D Carving, Precision Cutting, Automatic Tool Change Optional

Color
Blue/White/Custom

Command Code
G Code

Collet Type
ER20

Spindle Power
3 kW Water Cooled Spindle

Resolution
0.01 mm

Cooling Mode
Water Cooling

Repeat Positioning Accuracy
0.05 mm

Operating System
Windows (PC Based)

Travel (X, Y, Z)
900 1200 200 mm

Software Compatibility
ArtCAM, Type3, Ucancam, Mach3, Aspire

Control System
DSP A11 / NK105 / Mach3 (User Option)

Max Travelling Speed
15000 mm/min

Dust Collector
Optional External Dust Collector

Max Working Speed
8000 mm/min

High Speed CNC Wood Carving Machine (9001200 mm) with 3 kW Spindle for 3D Carving Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Week

Delivery Time
1 Week

Main Domestic Market
All India

About High Speed CNC Wood Carving Machine (9001200 mm) with 3 kW Spindle for 3D Carving

High Speed CNC Wood Carving Machine (900-1200 mm) with 3 kW Spindle for 3D Carving

6,30,001Get Latest Price

Working Area	900-1200 mm
X-Y Axis Working Area	600 x 600 mm
XY Axis Working Area	600 x 600 mm
Spindle Power	3 kW
Application	3D Carving
Z Axis Working Area	150 mm
Automatic Grade	Fully Automatic
Material	Wood ,Plastics and Non metal
Frequency (Hz)	50-60 Hz
Job Material	Wood
Weight (kg)	930 kg
Voltage	220 V
Dimension	308019201500 cm
Country of Origin	Made in India
